This system is designed for advanced R&D and quality control applications. Its enhanced force and heating capabilities support a wide range of advanced research activities, while its improved accuracy and resolution enable precise supplier monitoring and reliable quality assurance.
Optimized for Thermal Characterization of
Gap fillers
Greases
Pads
Foils
Underfills
Substrates
System Specs:
- ASTM D5470-17 compliant steady-state thermal characterization
- Benchtop system with 65.4 × 58 cm² footprint and 81.2 cm height
- 75 kg system weight and 1200 W power consumption
- Supports 12.7–38.1 mm round samples and 10–38.1 mm square samples
- Handles sample thicknesses from 0.001–40.0 mm
- Applies -400 … 900 N continuous force and -500 … 1000 N short-term force
- Measures BLT with 1 µm precision
- Covers 10–200 °C sample temperature range
- Provides 0.4 mm²K/W thermal resistance resolution and ±3% precision
- Supports automated testing varying thermal and mechanical parameter together
